    Milling 5-Axis Cnc Machine For Home

    Ask Lasest Price
    Brand Name : GUANGLIJIN
    Model Number : G5-220 Micro Five-Axis Engraving And Milling Machine
    Certification : CE Certificate
    Delivery Time : 30 days
    Payment Terms : T/T
    Supply Ability : 100 units/month
    • Product Details
    • Company Profile

    Milling 5-Axis Cnc Machine For Home

    Technical Parameters:

    No.ItemDetails
    1B axis reducerAlpha, GermanyRated torque 44.6n.m,
    Instaneous max. torque 156n.m,
    Rated speed 43 rpm, max. speed 85 rpm
    2C axis reducerJapanRated torque 6.4n.m,
    Instaneous max. torque 22.3n.m,
    Rated speed 300 rpm, max. speed 600 rpm
    3Transmission componentsRexroth, GermanyRepeatability: +/-0.005mm
    4OperationSYNTEC system10.4'' touch screen
    5Servo motor400w/ 200w
    6Spindleelectric2.5kw, max. speed 60000 rpm
    water cooling with flow-alarm
    7Tool magazineservo-driveUp to 12 tools
    8Tool holderISO 10
    9Collet chuckER-11
    10LubricationTiming automatic oiling
    11Working flatness+/-0.005mm
    12X axis stroke220mm
    13Y axis stroke105mm
    14Z axis stroke115mm
    15Body weight0.5 tons
    16Front doorsingle swinging door
    17Layout (mm)main body620 width*740 depth*1520 height
    18Power requirement220v/50hz
    Milling 5-Axis Cnc Machine For Home

    Support and Services:

    Technical support
    Installation
    Training
    Maintenance
    Troubleshooting
    Software upgrade


    Packing and Shipping:

    Fumigation wooden case by sea or by air


    FAQ:

    Q: Are you a dealer or manufacturer?
    A: We, Guanglijin, is a manufacturer of CAD/CAM CNC machine with over 20 years experience.
    Q: Where are you from?
    A: We are from Shenzhen China, one of the most creative city in the world.
    Q: Do you provide overseas support or service?
    A: Yes, we have a technican team which can travel abroad to do global service and support.
    Q: Does this machine come with any certification?
    A: Our machines are CE certificated.
