Technical Parameters:
| No. | Item | Details |
| 1 | B axis reducer | Japan | Rated torque 15.3n.m,
Instaneous max. torque 53.5n.m,
Rated speed 250rpm, max. speed 500 rpm |
| 2 | W axis spindle | servo motor | max. 10000rpm,
max. dia. of round cutter: 70mm |
| 3 | Transmission components | Rexroth, Germany | Repeatability: +/-0.003mm |
| 4 | Operation | SYNTEC system | 220MB-10.4 inch screen operation box,
max. extending 500mm on width at left side |
| 5 | Servo motor | | 50w/400w/750w |
| 6 | Spindle | Air-operated | 2.5kw, max. speed 60000 rpm
water cooling with flow-alarm |
| 7 | Tool magazine | | Auto calibration: 0.002mm Up to 8 tools |
| 8 | Bead rolling | servo-drive | 250 rpm to 500 rpm |
| 9 | Loading&unloading | servo-motor | vacuum chuck |
| 10 | Tool holder | Penumatic driving | ISO 10 |
| 11 | Collet chuck | | ER-11 |
| 12 | Lubrication | | Timing automatic oiling |
| 13 | Working flatness | | +/-0.015mm |
| 14 | X axis stroke | | 180mm |
| 15 | Y axis stroke | | 50mm |
| 16 | Z axis stroke | | 130mm |
| 17 | Body weight | | 1.0 tons |
| 18 | Front door | Penumatic driving | extending 600mm upward when opened |
| 19 | Layout (mm) | main body | 840 width*970 depth*2100 height |
| 20 | Power requirement | | 220v/50hz |
Support and Services:
Technical support
Installation
Training
Maintenance
Troubleshooting
Software upgrade
Packing and Shipping:
Fumigation wooden case by sea or by air
FAQ:
Q: Are you a dealer or manufacturer?
A: We, Guanglijin, is a manufacturer of CAD/CAM CNC machine with
over 20 years experience.
Q: Where are you from?
A: We are from Shenzhen China, one of the most creative city in the
world.
Q: Do you provide overseas support or service?
A: Yes, we have a technican team which can travel abroad to do
global service and support.
Q: Does this machine come with any certification?
A: Our machines are CE certificated.
