    G7-500 Laser Engraving And Milling Batch Machine

    Ask Lasest Price
    Brand Name : GUANGLIJIN
    Model Number : G7-500 Laser Engraving And Milling Batch Machine
    Certification : CE Certificate
    Payment Terms : T/T
    Supply Ability : 100 units/month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    G7-500 Laser Engraving And Milling Batch Machine

    Technical Parameters:

    No.ItemDetails
    1C axis reducerJapanrated torque 12.7n.m,
    Instaneous max. torque 44.6n.m,
    Rated speed 300 rpm, max. speed 600 rpm
    2Transmission componentsRexroth, GermanyRepeatability: +/-0.005mm
    3OperationRexroth systemP911174057 CML75.1-3P-905-NA-NNNN-NW
    4Servo motorRexroth, Germany400w
    5Main spindleelectric3.7kw, max. speed 40000 rpm
    water cooling with flow-alarm
    6Tool magazineservo-driveUp to 15 tools
    7Tool calibrationauto settingspeed 50-200mm/min, accuracy 0.002mm
    8Tool holderISO20
    9Collet chuckER-16
    10LubricationTiming automatic oiling
    11Working flatness+/-0.015mm
    12X axis stroke500mm
    13Y axis stroke130mm
    14Z1 axis stroke250mm
    15Z2 axis stroke155mm
    16Body weight1.6 tons
    17Front doorsliding door
    18Layout (mm)main body800 width*1000 depth*2100 height
    19Power requirementthree-phase380v/50hz

    G7-500 Laser Engraving And Milling Batch Machine

    Support and Services:

    Technical support
    Installation
    Training
    Maintenance
    Troubleshooting
    Software upgrade


    Packing and Shipping:

    Fumigation wooden case by sea or by air


    FAQ:

    Q: Are you a dealer or manufacturer?
    A: We, Guanglijin, is a manufacturer of CAD/CAM CNC machine with over 20 years experience.
    Q: Where are you from?
    A: We are from Shenzhen China, one of the most creative city in the world.
    Q: Do you provide overseas support or service?
    A: Yes, we have a technican team which can travel abroad to do global service and support.
    Q: Does this machine come with any certification?
    A: Our machines are CE certificated.
