High-Performance Five Axis Jewelry Carving Machine for Intricate Jewelry Design

Shenzhen Guanglijin Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap High-Performance Five Axis Jewelry Carving Machine for Intricate Jewelry Design from wholesalers

    Buy cheap High-Performance Five Axis Jewelry Carving Machine for Intricate Jewelry Design from wholesalers
    • Buy cheap High-Performance Five Axis Jewelry Carving Machine for Intricate Jewelry Design from wholesalers

    High-Performance Five Axis Jewelry Carving Machine for Intricate Jewelry Design

    Ask Lasest Price
    Brand Name : guanglijin
    Certification : CE Certificate
    Delivery Time : 30 days
    Payment Terms : T/T
    Supply Ability : 100 units/month
    Model Number : G5-430 Five-axis sheet engraving machine
    • Product Details
    • Company Profile

    High-Performance Five Axis Jewelry Carving Machine for Intricate Jewelry Design

    Technical Parameters:

    G5-430
    No.ItemDetails
    1Transmission componentsRexroth, GermanyRepeatability: +/-0.005mm
    2OperationSYNTEC system220MB-5, 10 inch screen operation box
    3Servo motor200W/400W/750W
    4SpindleElectric3.7kw, max. speed 45000 rpm water cooling with flow-alarm
    5Tool magazineServo-driveUp to 10 tools
    6Tool holderHSK E25
    7Collet chuckER-16
    8Sheet widthmax. 90mm
    9LubricationTiming automatic oiling
    10Working flatness+/-0.005mm
    11X axis stroke430mm
    12Y axis stroke120mm
    13Z axis stroke115mm
    14Body weight1.5 tons
    15Front doorpenumatic door
    16Layout (mm)Main body1600 width*1000 depth*2400 height
    17Power requirementthree-phase380v/50hz

    High-Performance Five Axis Jewelry Carving Machine for Intricate Jewelry Design

    Support and Services:

    Technical support
    Installation
    Training
    Maintenance
    Troubleshooting
    Software upgrade


    Packing and Shipping:

    Fumigation wooden case by sea or by air


    FAQ:

    Q: Are you a dealer or manufacturer?
    A: We, Guanglijin, is a manufacturer of CAD/CAM CNC machine with over 20 years experience.
    Q: Where are you from?
    A: We are from Shenzhen China, one of the most creative city in the world.
    Q: Do you provide overseas support or service?
    A: Yes, we have a technican team which can travel abroad to do global service and support.
    Q: Does this machine come with any certification?
    A: Our machines are CE certificated.
